PZ72L-DE Smart Panel mounted DC Energy Meter
Acrel Pz72L-De DC Electricity Meter Kwh Meter Power Analyzer for Solar Power Mornitoring

Acrel Pz72L-De DC Electricity Meter Kwh Meter Power Analyzer for Solar Power Mornitoring

General
PZ series intelligent DC energy meter is designed for applications such as DC panels, solar power, telecommunications base stations,and charging posts. This series of instruments can measure voltage, current, power, forward and reverse power in DC system. It can be used for local display, and connected with industrial control equipment, computers, form a measurement and control system. And it has a variety of external excuse functions for the user to choose: RS485 communication interface, Modbus-RTU protocol, relay alarm output, digital input/output. According to different requirements, through the instrument panel keys, you can set the ratio, communication parameters.

Features
True RMS Measurements
Unbalance & Phase Angles
Demands and Multi-Tariff energy
Max/Min Log with Time stamp
Alarms and SOE Logs
External Option module

Types and Functions

Type	Basic Function	Exterior	Optional Function
PZ72L-DE	voltage,current,power,energy,LCD desplay	72 square	1.--RS485 (/C) 2.--12V power output Δ (/V) 3.--RS485 + 2DO (/KC) 4.--RS485 + 2DI2DO (/KC) 5.--RS485 + 2DO + 12V power output (/KVC) 6.--RS485 + 12V power output (VC) The above functions can have the following two optional functions at the same time: 7.--Auxiliary power 20-60V (/ZD) 8.--Multiple rate (F)
PZ72-DE	voltage,current,power,energy,LCD desplay	72 square

Annotation: Δ The functon of 12V power output and DI can not be selected at the same time.

Technical Parameters

Technical Parameters		Indicators
Input	DC voltage	Input range		0~100V,0~500V,0~1000V
		Input resistance		≥6kΩ/V
	DC current	Input range		(External Shunt or Hall Current Sensor, the range can be set)
		Shunt		75mV
		Hall Current Sensor		0~20mA,0~5V
		Power consumption		≤1mW
	Overload	It can work at normal status at 1.2 times of full load, and can contined work 1 second at 2 times of full load.
Accuracy class		0.5class
Function	Measuring	Voltage,Current,Power
	Calculate	Current total electricity,Current positive energy,Current reverse power
	Multiple rate	Four time zones,two time table,fourteen time points,four multiple rates. (PZ72L-DE support only)
	Historical data statistics	Last 12 months of historical electricity(multiple rate electricity).(PZ72L-DE support only)
	DI,DO	2DI(Collect and display local switch status information,Realize remote transmission by RS485),2DO(Relay output, can achieve "remote control" and alarm output)
	Display	LCD(the backlight delay time can be adjusted) or LED
	Communication	RS485,Half duplex,Photoelectric isolation,Modbud-RTU / DL/T645-07,Band:1200/2400/4800/9600,Infrared:1200
	DI,DO	DI	Dry contact input, Meter built-in power supply, photoelectric isolation
		DO	Two relay outputs, Normally open contact, capacity:2A/30VDC or 2A/250VAC
Working power	Voltage range	85~265VAC/DC,50/60Hz;20~60VDC
	Power consumption	≤2W
Insulation resistance		≥100MΩ
Power frequency withstand voltage		3kV/1min(RMS)(between the power supply binding post and the signal binding post)
Environment	Temperature	Working Temp:-20ºC~+60ºC;Storage Temp:-20ºC~+70ºC
	Humidity	≤ 93%RH No condensation, no corrosive gases
	Altitude	≤ 2500m
