Pol-01 Medical Equipment Optical Slit Lamp Microscope
SpecificationMicroscopeType5-stage magnificationChange with parallel tubesValue on magnificationChange knob2.5, 1.5, 1, 0.66, 0.4Eyepieces10x, Papillary adjustable55-75mm, diopterAdjustable &p......
Send Inquiry
Product Description
Specification
Microscope
Type5-stage magnification
Change with parallel tubesValue on magnification
Change knob2.5, 1.5, 1, 0.66, 0.4
Eyepieces10x, Papillary adjustable
55-75mm, diopter
Adjustable ± 5DRotation angle of
MicroscopeHorizontal 180°
(90° For left and right)
Working distance92mmTotal magnification4.99x~31.2x
Slit illumination
Silt width(mm)0-14, continuously
AdjustableSlit length(mm)Adjustable and
0.5, 1, 3, 5, 10, 14step
Silt angle0° -180° With horizontal
(90° Or left and right) scanning
Capability 0° 20° ) with vertical
Scanning capabilityFilters
Green, cobalt blue, ND(28%)
Lamp12V, 30W halogen lamp
Base
Longitudinal movement100mmLateral movement110mm
Fine movement14mmVertical movement30mm
Lift range of chin rest50mm
Elevation table
Vertical movement200mmInput voltage220V 50HZ
Power consumption<180W
Microscope
Type5-stage magnification
Change with parallel tubesValue on magnification
Change knob2.5, 1.5, 1, 0.66, 0.4
Eyepieces10x, Papillary adjustable
55-75mm, diopter
Adjustable ± 5DRotation angle of
MicroscopeHorizontal 180°
(90° For left and right)
Working distance92mmTotal magnification4.99x~31.2x
Slit illumination
Silt width(mm)0-14, continuously
AdjustableSlit length(mm)Adjustable and
0.5, 1, 3, 5, 10, 14step
Silt angle0° -180° With horizontal
(90° Or left and right) scanning
Capability 0° 20° ) with vertical
Scanning capabilityFilters
Green, cobalt blue, ND(28%)
Lamp12V, 30W halogen lamp
Base
Longitudinal movement100mmLateral movement110mm
Fine movement14mmVertical movement30mm
Lift range of chin rest50mm
Elevation table
Vertical movement200mmInput voltage220V 50HZ
Power consumption<180W
| MOQ | 1 set |
| Delivery time | 7-10 days after payment |
| Payment terms | T/T |
| Warranty period | 1 year |
